Siemens SIMATIC DP Interface Module IM151-1 High Feature for ET 200S

Order number / MLF: 6ES7151-1BA02-0AB0
Product type designation: IM 151-1 HF
Lifecycle note: Spare part

Description / Function

• Interface module for SIMATIC ET 200S distributed I/O; connects ET 200S to PROFIBUS DP via RS-485

• Isochronous mode: supported

• Operates as DPV0 or DPV1 slave

• Max. 63 modules can be connected (ET 200S station)

• Bus connection via 9-pin D-sub, including termination module

Key Specifications (Data)

PROFIBUS / Communications

• Transmission procedure: RS-485

• Max transmission rate: 12 Mbit/s

• PROFIBUS DP: Yes (PROFINET IO: No)

• PROFIBUS services: SYNC yes; FREEZE yes; Direct data exchange (slave-to-slave) yes

I/O Address Space

• Addressing volume (max): Inputs 244 bytes, Outputs 244 bytes

Power / Electrical

• Mains/voltage failure stored-energy time (buffering): 20 ms

• Input current from supply voltage 1L+ (max): 200 mA

• Power loss (typ.): 3.3 W

• Isolation tested with: 500 V DC

• Potential separation:

  • Backplane bus ↔ electronics: No

  • Electronic block ↔ PROFIBUS DP: Yes

  • Supply voltage ↔ electronics: No

Diagnostics / Status

• Alarms: Yes

• Diagnostics function: Yes

• LEDs: BF (red) bus fault, SF (red) group error, ON (green) 24 V supply monitoring

Environmental

• Operating temperature: 0 to 60 °C

Mechanical

• Dimensions (W × H × D): 45 mm × 119.5 mm × 75 mm

• Weight: ~150 g

Conformances (as listed in datasheet)

• CE mark: Yes; UL approval: Yes
