QNAP TS-1277 SAN/NAS Storage System - AMD Ryzen 7 1700 Octa-core (8 Core) 3 GHz - 12 x HDD Supported - 4 x SSD Supported - 64 GB RAM DDR4 SDRAM - Serial ATA/600 Controller - RAID Supported 0, 1, 5, 6, 10, 50, 60, Hot Spare, JBOD - 12 x Total Bays - 8 x 3.

QNAP TS-1277 SAN/NAS Storage System - AMD Ryzen 7 1700 Octa-core (8 Core) 3 GHz - 12 x HDD Supported - 4 x SSD Supported - 64 GB RAM DDR4 SDRAM - Serial ATA/600 Controller - RAID Supported 0, 1, 5, 6, 10, 50, 60, Hot Spare, JBOD - 12 x Total Bays - 8 x 3.5" Bay - 4 x 2.5" Bay - 3 x Total Slot(s) - Gigabit Ethernet - HDMI - 8 USB Port(s) - 6 USB 3.0 Port(s) - Network (RJ-45) - QTS 4.3 - DNS, Telnet, DLNA, IPv6, FTPS, WEBDAV, SSL/TLS, AFP, CIFS, HTTPS, FTP, ... - 512 MB Flash Memory Capacity - TAA Compliance

TS-1277 The first Ryzen™-based NAS with up to 8 cores and 16 threads and graphics card support to redefine your virtualization and 4K processing experiences The TS-1277 powered by AMD''s new 14nm Ryzen™ processor redefines the high-end desktop business NAS for greater video and virtual machine performance with up to 8 cores/16 threads native processing and Turbo Core up to 3.7 GHz. Cutting-edge hardware integrated with multitasking software makes the TS-1277 the preeminent choice to tackle resource-demanding applications and tasks. Two M.2 SATA 6Gb/s SSD slots for caching or caching pools to accelerate system performance. PCIe expandability allows for 10GbE/40GbE adapters, PCIe NVMe SSD, graphics cards, USB 3.1 10Gbps cards, or wireless network cards. Supports AMD Radeon™ and NVIDIA® graphics cards for video processing or GPU-passthrough to VMs. Qtier™ technology and SSD caching enable 24/7 optimized storage efficiency. Scalable storage supporting virtualization, containerized apps, centralized storage, backup, sharing, and disaster recovery. RAID 50/60 is recommended for NAS with over 10 disks to strike a balance between capacity, protection, and performance. Absolute performance with AMD Ryzen™ and up to 64GB RAM Powered by a high-performance AMD Ryzen™ 7 1700 or AMD Ryzen™ 5 1600 processor with AES-NI encryption acceleration and up to 64GB DDR4 RAM, the TS-1277 delivers aggressive yet power-smart performance to meet your multitasking demands and is capable of running up to 16 virtual machines simultaneously*. For resource-demanding business applications such as VDI, R&D, private cloud, and server virtualization, the TS-1277 with gold-standard performance is your ideal choice. Top-class hardware engineering The feature-packed hardware of the TS-1277 bolsters overall system performance. Coupled with the flexible and expandable architecture, the TS-1277 fulfills diversified application needs. Extend NAS functionality with PCIe slots The TS-1277 features three PCIe slots (1 x PCIe 3.0 x8, 1 x PCIe 3.0 x4, 1 x PCIe 2.0 x4) that allow for installing 10GbE/40GbE network cards, QM2 M.2 SSD/10GbE PCIe cards, or compatible wireless network cards for greater application potential. Fuel GPU-accelerated computing with a 550W power supply Graphics cards are optimized for graphical calculations and transformations, but require significantly more power compared to other hardware. The TS-1277 offers PCIe slots to support AMD Radeon™ or NVIDIA® graphics cards and a 550 watt power supply that is capable of powering a graphics card for boosting imaging processing in QTS and performance of virtual machines via GPU passthrough. When enjoying videos with the TS-1277, you can use the remote control (RM-IR004, optional purchase) that supports QButton for a more convenient control of your multimedia experience.

Technical Specifications:
Number of Hard Drives Supported: 12
Number of Hard Drives Installed: No
Number of Solid State Drive Supported: 4
Number of Solid State Drive Installed: No
Flash Memory Capacity: 512 MB
Processor Manufacturer: AMD
Processor Type: Ryzen 7
Processor Model: 1700
Processor Core: Octa-core (8 Core)
Processor Speed: 3 GHz
Standard Memory: 64 GB
Memory Technology: DDR4 SDRAM
Ethernet Technology: Gigabit Ethernet
Number of Total Expansion Bays: 12
Number of 3.5" Bays: 8
Number of 2.5" Bays: 4
Number of Total Expansion Slots: 3
Controller Type: Serial ATA/600
RAID Supported: Yes
RAID Levels: 0, 1, 5, 6, 10, 50, 60, Hot Spare, JBOD
HDMI: Yes
Total Number of USB Ports: 8
Number of USB 3.0 Ports: 6
Network (RJ-45): Yes
Operating System: QTS 4.3
Protocols: DNS, Telnet, DLNA, IPv6, FTPS, WEBDAV, SSL/TLS, AFP, CIFS, HTTPS, FTP, SSH, DHCP, SMTP, FXP, LDAP, iSCSI, IPv4, UPnP, PPTP, TCP/IP, HTTP, DDNS, CIFS/SMB, SNMP, RSync
Height: 9.2"
Width: 14.6"
Depth: 12.6"
Form Factor: Tower
Weight (Approximate): 25.35 lb
Package Contents:

TS-1277 SAN/NAS Storage System, 2 x Ethernet Cables, Quick Installation Guide (QIG), Flat Head Screws (For 2.5" HDD), Flat Head Screw (For M.2 SSD), 1 x Power Cord, 2 x M.2 SSD Cooling Module
