Promise VTrak Jx30 Expansion Chassis - 24 x HDD Supported - 24 x HDD Installed - 96 TB Installed HDD Capacity - RAID Supported JBOD - 24 x Total Bays - 24 x 2.5"/3.5" Bay - 4U - Rack-mountable - RoHS, WEEE Compliance J830SDQS4

Promise VTrak Jx30 Expansion Chassis - 24 x HDD Supported - 24 x HDD Installed - 96 TB Installed HDD Capacity - RAID Supported JBOD - 24 x Total Bays - 24 x 2.5"/3.5" Bay - 4U - Rack-mountable - RoHS, WEEE Compliance

As the demands for capacity expansion of digital media continues to explode, IT infrastructures and its growing complexities have become increasingly difficult to manage. With no end in sight of this storage boom, IT administrators are faced with finding a robust storage expansion platform to serve as a building block to provide high-availability, flexibility and energy-efficiency in a cost effective package that meets their application demands.Delivering a reliable enterprise-level storage architecture The VTrak Jx30 series 6G SAS subsystems deliver a high performance SAS solution with advanced enterprise level reliability and functionality. Delivered in a Storage Bridge Bay (SBB) 2.0 compliant package, the Jx30 series offers the full redundancy that is expected of an enterprise solution. Dual active-active JBOD I/O modules allow for redundant data paths to ensure data availability while dual power supplies and cooling fans are in place to minimize downtime and any disruption to business continuity.6G SAS Performance Providing up to 24Gb/s of bandwidth over the external multilane 6G SAS host interface, the VTrak Jx30 series allows storage applications to access their data at blistering speeds. The 6G SAS architecture paves the way for immense available bandwidth to support the flood of unstructured data now flowing across networks today. Fully backward compatible with 3G SAS/SATA devices, users have the ability to deploy 3G

Technical Specifications:
Number of Hard Drives Supported: 24
Number of Hard Drives Installed: 24
Total Hard Drive Capacity Installed: 96 TB
Hard Drive RPM: 7200
Number of Total Expansion Bays: 24
Number of 2.5"/3.5" Bays: 24
RAID Supported: Yes
RAID Levels: JBOD
Drive Interface: Near Line SAS (NL-SAS)
Host Interface: Mini-SAS
Protocols: SES, SMP
Input Voltage: 110 V AC, 220 V AC
Maximum Power Supply Wattage: 750 W
Height: 6.9"
Width: 17.6"
Depth: 20"
Form Factor: Rack-mountable
Rack Height: 4U
Weight (Approximate): 57.30 lb
Certifications & Standards: CE, FCC Class A, UL/cUL, TUV, BSMI Class A, VCCI Class A, CB, KCC, NOM, GOST-R, IRAM, C-Tick, S-Mark
Environmentally Friendly: Yes
Environmental Certification: RoHS, WEEE
