Astec Power Supply DC-1 Laser 255w 24-48V 0.32A 10.4A LPS255-C

Astec Power Supply DC-1 Laser 255w 24-48V 0.32A 10.4A LPS255-C
Astec Power Supply DC-1 Laser 255w 24-48V 0.32A 10.4A LPS255-C
Brand: Astec
Part Number: LPS255-C
MSRP: $1,794.99
Availability: 10 or more
Condition: Refurbished
Price: $1,495.00
Qty:     - OR -   Add to Wish List
Add to Compare

Astec Power Supply DC-1 Laser 255w 24-48V 0.32A 10.4A LPS255-C

• Active power factor correction
• IEC EN6100-3-2 compliance
• Remote sense & remote inhibit
• Power fail
• Single wire current sharing
• Built-in EMI filter
• Low output ripple
• 2 Supervisory outputs 5 V and 12 V
• Overvoltage protection
• Overload protection
• Thermal overload protection
• DC power good
• Cover -C
• 120 kHz switching frequency
• Optional top with fan cover -CF
• Optional end fan cover -CEF

Operating temperature: 0° to 50°C ambient
derate each output at 2.5% per degree from 50° to
70°C
Electromagnetic susceptibility: Designed to meet
IEC 801, -2, -3, -4, -5, -6, Level 3
Humidity: Operating; non-condensing
5% to 95%
Vibration: Three orthogonal axes, sweep at
1 oct/min, 5 min. dwell at four major resonances
0.7 G peak 5 Hz to 500 Hz, operational
Storage temperature: -40° to 85°C
Temperature coefficient: ±.04% per °C
MTBF demonstrated: >550,000 hours at full load
and 25°C ambient conditionsation
