ASRock Z77 WS LGA1155/ Intel Z77/ DDR3/ Quad CrossFireX & Quad SLI/ SATA3&USB3.0/ A&2GbE/ ATX Motherboard

Specifications

• Mfr Part Number: Z77 WS
• CPU: LGA1155
  • Supports 3rd and 2nd Generation Intel Core i7/ i5/ i3/ Pentium/ Celeron/ Xeon Processors
  • Digi Power Design
  • 8 + 4 Power Phase Design
  • Supports Intel Turbo Boost 2.0 Technology
  • Supports Intel K-Series Unlocked CPU
  • Supports Hyper-Threading Technology
• Chipset: Intel Z77
• Memory: 4x DDR3-3000+(OC)/ 2400(OC)/ 2133(OC)/ 1866(OC)/ 1600/ 1333/ 1066 DIMM Slots, Dual Channel, Non-ECC, Unbuffered, Max Capacity of 32GB
• Slots: 5x PCI-Express 3.0 x16 Slots (one run at x16 or x16/0/16/0 or x8/8/8/8), 1x PCI-Express 2.0 x16 Slot (runs at x4), 1x PCI-Express 2.0 x1 Slot
• Multi-Graphics: Supports AMD Quad CrossFireX, 4-Way CrossFireX, 3-Way CrossFireX, CrossFireX and NVIDIA Quad SLI, 4-Way SLI, 3-Way SLI, SLI Technology
• SATA: 6x SATA3 Ports, Two Support RAID 0, 1, 5, 10; 4x SATA2 Ports, Support RAID 0, 1, 5, 10
• Audio: Realtek ALC898 7.1-Channel High Definition Audio CODEC, Supports Premium Blu-ray Audio
• Video: Intel HD Graphics 2500/4000 w/ Intel CPU, Maximum Shared Memory of 1760MB
• LAN: Broadcom BCM57781 PCI-Express x1 Gigabit Ethernet Controller
• Ports: 12x USB 3.0 Ports (8 rear, 4 via headers), 8x USB 2.0 Ports (2 rear, 6 via headers), 1x PS/2 Keyboard/Mouse Port, 1x HDMI Port, 1x eSATA3 Port, 1x Optical SPDIF Out, 2x RJ45 LAN Ports, 1x IEEE 1394 Port, Audio I/O Jacks
• Power Connector: 1x 24pin ATX Power Connector, 1x 8pin 12V Power Connector
• Form Factor: ATX, 12.0 x 9.6 inch / 30.5 x 24.4 cm
